Photodiode Circuit Design Considerations

Simplified Photoconductive Mode Implementation
By simply loading the photodiode with a ~50Ω resistor, you can achieve significant benefits in photoconductive mode:

• No forward bias required if diode voltage remains below 20mV

• Delivers reasonably fast response times

• Tradeoff: Reduced sensitivity

Avalanche Photodiodes (APDs)

• Require reverse bias near breakdown voltage

• Provide internal current amplification for low-light detection

Selection Tradeoffs
Key parameters to balance when selecting photodiodes:

1. Active area size

2. Junction capacitance

3. Noise characteristics

4. Dark current

5. Package type

Design Recommendation

• Opt for smaller photodiodes with built-in reflectors/lenses for light concentration

• Note: Texas Instruments doesn't manufacture discrete photodiodes

• For basic applications, consider OPT101 - an integrated solution combining photodiode and transimpedance amplifier

Author's Note
"Many engineers specialize in photodiode circuit design, and high-performance applications require deep expertise. While I'm not an authority on this subject - nor most topics I discuss - I share my knowledge through blogs rather than textbooks.

We'd love to hear:

• Have you implemented photodiodes for unconventional applications?

• Experts are welcome to contribute additional insights!"
